Bow Type Drop Black FTTH Fiber Optic Cable 2 Core FRP GJYXCH

2 core FRP GJYXCH bow-type drop cable Black FTTH Fiber Optic Cable

Description

The GJYXCH FTTH fiber optical fiber unit is positioned in the centre.Two parallel Fiber Reinforced Plastics (FRP) are placed at the two sides.

1. Special Low-bend-sensitivity fiber provides high bandwidth and excellent communication transmission property.
2. Two parallel FRP strength members ensure good performance of crush resistance to protect the fiber.
3. Single steel wire as the additional strength member ensures good performance of tensile strengh.
4. Simple structure, light weight and high practicability.
5. Novel flute design, easily strip and splice, simplify the installation and maintenance.
6. Low smoke,zero halogen and flame retardant sheath.

Features

1. Compact structure of protable, convenient for indoor wiring.

2. Excellent resistance to lateral pressure protection design.

3. Soft, flexible, easy to splice, and high practicability.

4. Environmental protection. Low smoke, zero alogen and flame retardant sheath.

Applications

1. Used in indoor outdoor cabling,especially used for FTTH.
2. Used as access building cable.

Cable Parametres

Model No.	Fiber count (core)	Cable diametre (mm)	Weight (kg/km)	Tensile Strength Long/Short Term (N)	Crush Resistance Long/Short Term (N)	Bending Radius Static/Dynamic (mm)
GJYXCH	1	(2.1±0.1)×(5.1±0.1)	21	1500/2500	500/1300	15/30
GJYXCH	2	(2.1±0.1)×(5.1±0.1)	21	1500/2500	500/1300	15/30
GJYXCH	4	(2.1±0.1)×(5.1±0.1)	21	1500/2500	500/1300	15/30

Fiber Type	Attenuation		Overfilled launch Bandwidth	Effective Modal Bandwidth	10GB/S Ethernet link length	Min Bending Radius
Conditions	1310/1550nm	850/1300nm	850/1300nm	850nm	850nm
Unit	dB/km	dB/km	MHZ.km	MHZ.km	m	mm
G652D	0.36/0.22					16
G657A1	0.36/0.22					10
G657A2	0.36/0.22					7.5
50/125		3.0/1.0	≥500/500			30
62.2/125		3.0/1.0	≥200/500			30
OM3		3.0/1.0	≥1500/500	≥2000	≥300	30
OM4		3.0/1.0	≥3500/500	≥4700	≥550	30
B1-OM3		3.0/1.0	≥1500/500	≥2000	≥300	7.5
B1-OM4		3.0/1.0	≥3500/500	≥4700	≥550	7.5

We produce and test cable comply with following standard

Mechanical Performance
Max Tension Performance	IEC 60794–1-2-E
Max. Operation Tension	IEC 60794–1-2-E1
Crush Test	IEC 6079 –1-2-E3
Impact Test	IEC 60794–1-2-E4
Repeated Bending	IEC 60794–1-2-E6
Torsion Test	IEC 60794–1-2-E7
Cable bend	IEC 60794–1-2-E11A
Attenuation Coefficient	ITU-T G.652
Structural Test	IEC-60793-1-20
Environmental Performance
Temperature Cycling	IEC 60794–1-2-F1
Water Penetration	IEC 60794–1–2-F5B
Filing Compound Flow	IEC 60794-1-E14

Why Choose Us?

Production and Qulaity Test

Packing and Delivery

FAQ

Q1: Where is your factory ?
A1: Our factory is located in Deyang City, Sichuan Province, China.
Q2: How long has your company been doing this?
A2: More than 31 years.We are not only produce fiber optical cable but also produce optical fiber and related tools .
Q3: How about the cable's quality?
A4: Our factory is approved by ISO9001 quality management system and including STARF,CE,CPR,TLC certifications at list.We have a series of equipment and instruments to make sure reliable quality of our products.
Q4: Can you produce cable as our requirements?
A6: Of course .We can supply different types of products according to your requirements with reasonable prices .
Q5: Do you accept the OEM order and how many is the MOQ?
A7: Yes,we warmly welcome your OEM order.To achieve customer's satisfaction,we accept sample order, even one Piece.
